Description
|
Model
|
Cutting thickness (mm)
|
Cutting length (mm)
|
Motor (KW)
|
Dimension(mm)
|
Weight(t)
|
|
QC12Y-4X2500
|
4
|
2500
|
4
|
3100x1430x1500
|
3.8
|
|
QC12Y-4X3200
|
4
|
3200
|
5.5
|
3800x1670x1620
|
5.3
|
|
QC12Y-4X4000
|
4
|
4000
|
5.5
|
4600x1860x1850
|
6.8
|
|
QC12Y-6X2500
|
6
|
2500
|
7.5
|
3100x1540x1550
|
5
|
|
QC12Y-6X3200
|
6
|
3200
|
7.5
|
3800x1670x1620
|
5.8
|
|
QC12Y-6X4000
|
6
|
4000
|
7.5
|
4600x1860x1850
|
8.5
|
|
QC12Y-6X6000
|
6
|
6000
|
7.5
|
6650x2500x1980
|
17.8
|
|
QC12Y-8X2500
|
8
|
2500
|
11
|
3140x1600x1570
|
5.9
|
|
QC12Y-8X3200
|
8
|
3200
|
11
|
3800x1720x1700
|
7.5
|
|
QC12Y-8X4000
|
8
|
4000
|
11
|
4600x1930x1780
|
9.4
|
|
QC12Y-8X6000
|
8
|
6000
|
11
|
6680x2550x1990
|
20
|
|
QC12Y-12X2500
|
10
|
2500
|
18.5
|
3150x2000x1850
|
9.4
|
|
QC12Y-12X3200
|
12
|
3200
|
18.5
|
3150 x2000 x 1850
|
11.8
|
|
QC12Y-12X4000
|
12
|
4000
|
18.5
|
3850 x 2060 x 1900
|
14.3
|
|
QC12Y-12X6000
|
12
|
6000
|
18.5
|
4650 x 2350 x 1980
|
27
|
|
QC12Y-16X2500
|
12
|
2500
|
18.5
|
6680 * 2470 x2850
|
10
|
|
QC12Y-16X3200
|
16
|
3200
|
18.5
|
3180 x2150 *1880
|
13
|
|
QC12Y-16X4000
|
16
|
4000
|
18.5
|
3880 x2450 x2030
|
17
|
|
QC12Y-20X2500
|
16
|
2500
|
30
|
4680 x2650 * 2100
|
14.8
|
|
QC12Y-20X3200
|
20
|
3200
|
30
|
3180 x2420 x2020
|
18.5
|
|
QC12Y-20X4000
|
20
|
4000
|
30
|
3880 x2650 x2150
|
24
|
|
QC12Y-20X6000
|
20
|
6000
|
30
|
6750 x2350 x 3600
|
53
|
|
QC12Y-25X2500
|
25
|
2500
|
30
|
3280 x2650 x2300
|
19
|
|
QC12Y-32X2500
|
32
|
2500
|
37
|
3300 x2850 x2450
|
25
|
JIANGSU JINCHANGSHENG MACHINE TOOL CO., LTD.
Deeply rooted in Xinhong Industrial Park,Tangyang Town,Dongtai City,Jiangsu Province, which is renowned as the “Hometown of Shearing,Bending and Rolling”As a High -tech Enterprise and a Specialized, Sophisticated, Unique and Innovative Small and Medium-sized Enterprise in Jiangsu Province, the company has always been based on profound industry accumulation and driven by innovation, thus establishing itself as a professional model in the field of machinery manufacturing. Currently the company has obtained a number of core technical patents, covering cutting -edge areas such as equipment structure optimization and intelligent control.Moreover, it holds a complete set of import and export qualifications, building a solid foundation for its in – depth exploration of the global market.
Benefiting from its advantageous geographical location, the company has formed a three dimensional transportation network. The Coastal Expressway and the Jianghai Expressway run through the area, while the Xinchang Railway and the Ningqi Railway converge nearby. The Nantong Port and the Shanghai Port are in close proximity, and both Shanghai Hongqiao International Airport and Shanghai Pudong International Airport can be reached within a two-hour traffic circle. Such convenient transportation conditions not only ensure the efficient transportation of products but also create unique opportunities for technical exchanges and cooperation.
Q1.DOES THE PRODUCT SUPPORT WARRANTY?
THE WARRANTY PERIOD OF OUR PRODUCTS IS 12 MONTHS FROM THE DATE OF BILL OF LADING. DURING THE WARRANTY PERIOD, WE WILL PROVIDE ACCESSORIES.IF WE MAKE A DIFFERENCE IN QUALITY, WE WON’T CHARGE ANY FEES. IF THE FAULT IS CAUSED BY THE CUSTOMER’S MISTAKE WE WILL PROVIDE SPARE PARTS FOR THE CUSTOMER AT THE COST PRICE.WE CAN ALSO PROVIDE FLEXIBLE EXTENDED WARRANTY ACCORDING TO THE ACTUAL SITUATION.
Q2. CAN I USE MY OWN LOGO OR DESIGN ON THE PRODUCT?
YES, WE OFFER OEM/ODM SERVICES; YOUR LOGO AND DESIGN CAN BE INCORPORATED ONTO THE PRODUCT
Q3. DO YOU HAVE A FACTORY?
YES, WE HAVE A FACTORY LOCATED IN JIANGSU. WELCOME TO VISIT OUR COMPANY AND FACTORY. WE AREA PROFESSIONAL MANUFACTURER THAT OFFERS OEM/ODM SERVICES TO OUR CLIENTS.
Q4. WHAT IS THE PRODUCTION CAPACITY OF YOUR FACTORY?
OUR PRODUCTION CAPACITY ALLOWS US TO MANUFACTURE OVER 30 MACHINES PER MONTH.
Q5.WHEN WILL THE SHIPMENT BE MADE?
THE WARRANTY PERIOD OF OUR PRODUCTS IS 12 MONTHS FROM THE DATE OF BILL OF LADING. DURING THE WARRANTY PERIOD, WE WILL PROVIDE ACCESSORIES.IF WE MAKE A DIFFERENCE IN QUALITY, WE WON’T CHARGE ANY FEES. IF THE FAULT IS CAUSED BY THE CUSTOMER’S MISTAKE WE WILL PROVIDE SPARE PARTS FOR THE CUSTOMER AT THE COST PRICE.WE CAN ALSO PROVIDE FLEXIBLE EXTENDED WARRANTY ACCORDING TO THE ACTUAL SITUATION.
Q2. CAN I USE MY OWN LOGO OR DESIGN ON THE PRODUCT?
YES, WE OFFER OEM/ODM SERVICES; YOUR LOGO AND DESIGN CAN BE INCORPORATED ONTO THE PRODUCT
Q3. DO YOU HAVE A FACTORY?
YES, WE HAVE A FACTORY LOCATED IN JIANGSU. WELCOME TO VISIT OUR COMPANY AND FACTORY. WE AREA PROFESSIONAL MANUFACTURER THAT OFFERS OEM/ODM SERVICES TO OUR CLIENTS.
Q4. WHAT IS THE PRODUCTION CAPACITY OF YOUR FACTORY?
OUR PRODUCTION CAPACITY ALLOWS US TO MANUFACTURE OVER 30 MACHINES PER MONTH.
Q5.WHEN WILL THE SHIPMENT BE MADE?
ALL OF OUR PRODUCTS NEED TO BE ORDERED IN ADVANCE BEFORE PRODUCTION CAN BEGIN.
